Pinflex

This robust, general-purpose pin and buffer coupling provides reliable transmission of torque, and misalignment capability.



Coupling Capacity

  • Maximum power @100RPM - 340kW
  • Maximum torque -  32500Nm

Features & Benefits

  • Steel half bodies, strong yet compact
  • Heavy duty pin and buffer coupling - for heavy shock load conditions
  • Torsionally flexible - shock absorbing, extending machine life
  • Easy maintenance - minimum number of wearing parts; buffers can be changed without moving shafts
  • Misalignment capabilities - flexibility in installation
  • Polyurethane buffers - reliable, flexible and temperature-resistant
  • Modular construction - available in coupling, brakedrum and shear pin designs
  • Taper bore version available

Standard Range Comprises

  • Shaft to shaft
  • Shear Pin
  • Brake Drum/Disc

Applications

  • Conveyors
  • Escalators
  • Mixers
  • Pumps
  • General Industrial Applications

Construction Details

  • Steel half bodies
  • Urethane Buffer: Temp range -40°C to +80°C
